Imaging channels | Brightfield channel and 3 fluorescence channels (blue, green, and red) |
Light source | Blue channel: UV LED
Green channel: blue LED
Red channel: green LED
Brightfield channel: multiple green LEDs (reduces chromatic aberration) |
User interface | 10.1 in. color (26 cm) touch-screen LCD monitor, with anti-glare and anti-fingerprint treatment, 1,280 x 768 pixel image resolution, 80–180° angle tilt range |
Focusing mechanism | Coarse and fine, manual adjustment |
Camera | Monochrome camera, 12 bit CMOS, 5 megapixels |
Data format | JPEG, TIFF, or RAW image files |
Image merge | Images from up to 4 channels can be overlaid |
Data storage | 16 GB internal memory (~2,500 JPEG files,1,500 TIFF files, 400–800 RAW files) |
Data export | Yes, 2 USB ports |
Display output | Yes, 1 HDMI port |
Objective | 20x |
Numerical aperture | 0.40 |
Display magnification | Standard: 175x; zoom: 700x |
Maximum imaging area | 0.70 mm2 field of view |
Motorized stage | 6 mm travel in X, Y direction, touch-screen control of travel speed and direction |
Compatible with | Flasks: T25, T75, or T225
Multiwell plates: 6-, 12-, 24-, 48-, 96-, or 384-well microplates
Dishes: 35 mm, 60 mm, or 100 mm
Slides: chamber slides or standard glass microscopy slides |
Software | Stand-alone Android operating system; PC is not required for operation |
Instrument size (L x W x H) | 33 x 32 x 30 cm (13 x 12.6 x 11.6 in.) |
Instrument weight | 9 kg (19.7 lb) |
